染护一体电控梳子设计

姜淑凤 1 王博文 苏涵睿 马红雨 刘鑫

（齐齐哈尔大学机电工程学院 黑龙江省齐齐哈尔市 161006）

摘要：在日常生活中使用传统美发用品时，可能会遇到以下情况：长发者梳头时，头发缠在梳子

齿上；日常染发时，染发刷还需要配有装染发膏的盒子，而且容易将染发膏溅到别处，清理起来费时、
费力；洗发后，还需要配备吹风机才能吹干头发。为避免现有梳发染发护发过程中的繁琐工序以及弥

补美发用品多样而不易收纳整理的缺陷，可以利用现代机械创新方法设计出一款便携式染护一体多功
能梳子。其梳发齿柄后侧带有可以拆卸的染发梳壳体，且染发梳壳体与梳头相通，空腔结构内带有电

机驱动染护料口，可外接吹风机结构，并设有弹性开关。同时，在梳子齿后侧还添加了可推式刀片，
用于清理缠绕在梳齿上的头发。它集梳、吹、染、自清理等多种功能于一体。

关键词：多功能梳子；结构设计；干净环保；便携用品
Abstract: When using traditional hair products in daily life, it often happens that the hair is entangled in
the teeth of the comb. The hair-dye brush used in daily hair dyeing needs to be matched with the box

containing the hair-dye cream, etc. . Moreover, it is easy to spill the hair-dye cream somewhere else, cleaning

and cleaning are time-consuming and laborious; hair dryers are required after washing. In order to make up
for the defects that the existing combs and hair-care are complicated and the various articles are not easy to
receive and arrange, a kind of portable multi-functional comb with dyeing and care is designed by using

modern mechanical innovation method, the back of the comb handle is connected with the comb head by a

detachable comb shell, and the cavity structure is provided with a motor-driven dye-protecting mouth, which
can be connected with a hair dryer structure, and is provided with an elastic switch. At the same time, a
push-able blade is added to the back of the comb teeth to clean the hair that is wrapped around the comb teeth.

The utility model has the functions of combing, blowing, dyeing and self-cleaning.

Keywords: multifunctional comb; Structural design; Clean and environmentally friendly; Portable items

1 姜淑凤：（1979—），女，汉族，黑龙江齐齐哈尔人，教授，博士，研究方向为工业设计工程。
课题项目：黑龙江省教育科学十四五规划 2021 年度课题研究成果（GJB1421342）；齐齐哈尔大学大
学生创新创业项目，项目编号：x202210232125。
